CSGC-3000/EMS Energy Management System provides an integrated SCADA, AGC, PAS, DTS solutions to a large scale power control centers, which improves the stability and safety of the power grid.
SIFANG’s EMS solution consists of
• Servers relevantly for SCADA, PAS, AGC/AVC, history database, ICCP, DTS, Web, etc.,
• Front end communication server
• Workstations for operator consoles, maintaining, PAS, DTS, etc.
• Time synchronization device
• Firewall
• Video wall, etc.
Protection and fault Information Management System (PFIS) and Wide Area Measurement System (WAMS) can also be integrated in the system.
Redundant technology is used in every segment of the system including communication network, servers, front ends, firewall, etc.
Support multiple mainstream OSs, such as UNIX, Linux, Windows, etc., and heterogeneous, mixed mode of different OS.
Support multiple mainstream Data Base Management System (DBMS), such as ORACLE, MySQL, etc.
Hierarchical and distributed architecture, based on the object-oriented distributed modular design, the different application can be integrated by a ‘plug and play’ mode.
Support IEC 61970 CIM/CIS and IEC 61850
Integrated diagram, model and database can be implemented to reduce the system maintain work.
Distributed large-capacity real-time database and front end communication.
Provide power applications software, such as topology analysis, State Estimator (SE), Dispatcher Training Simulator (DTS), etc.
Intelligent alarming system, the monitoring is based on the primary and secondary models; expert system for intelligent judgment and treatment suggestion can be established.
Support the multimode operation based on the unified graph, such as real-time mode, analytic mode and replay mode.
Perfect security zone and subnet management
Introduced to the whole SCADA/EMS, SCADA Zone, DTS Zone, DMZ Zone and Office Zone are defined, isolated by the firewalls, more security and reliable isolate solution can be provided.
Security and convenient remote diagnosis technology can be supplied in order to implement the system hardware maintaining and application software debugging in the vendor’s factory remotely.
Provide the friendly, safe HMI for the operator by the browser style intelligence operation panel, RIA technique based B/S monitoring, geographic maps, etc.
